WIZnet W6300-EVB-Pico
The WIZnet W6300‑EVB‑Pico is an RP2040-based, Pico–compatible development board featuring the WIZnet W6300 hardwired TCP/IP Ethernet controller - it essentially works the same as Raspberry Pi Pico board, but with USB-C and the addition of Ethernet via a W6300 chip and Ethernet port.
The W6300 supports hardwired Internet protocols such as TCP, UDP, IPv6/IPv4, ICMPv6/ICMPv4, IGMP, MLDv1, ARP and PPPoE, offering eight independent simultaneous sockets with 32KB memory, 16KB of internal TX/RX buffer memory, and an SPI interface.
We also offer an RP2350-based version in the store, along with the rest of the WIZnet range.
Features
-
RP2040 microcontroller with 2MByte Flash
- Dual-core cortex M0+ at up to 133MHz
- 264kByte multi-bank high performance SRAM
- External Quad-SPI Flash with eXecute In Place (XIP)
- High performance full-crossbar bus fabric
- 30 multi-function General Purpose IO (4 can be used for ADC)
- 1.8-3.3V IO Voltage (NOTE. Pico IO voltage is fixed at 3.3V)
- 12-bit 500ksps Analogue to Digital Converter (ADC)
- Various digital peripherals
- 2 × UART, 2 × I2C, 2 × SPI, 16 × PWM channels
- 1 × Timer with 4 alarms, 1 × Real Time Counter
- 2 × Programmable IO (PIO) blocks, 8 state machines total
- Flexible, user-programmable high-speed IO
- Can emulate interfaces such as SD Card and VGA
-
Includes W6100
- Supports Hardwired Internet Protocols: TCP, UDP, IPv6, IPv4, ICMPv6, ICMPv4, IGMP, MLDv1, ARP, PPPoE
- Supports 8 independent sockets simultaneously with 32KB memory
- Internal 16 Kbytes Memory for TX/ RX Buffers
- SPI Interface
- USB-C port for power and data (and for reprogramming the Flash)
- 40 pin 21x51 'DIP' style 1mm thick PCB with 0.1" through-hole pins also with edge castellation
- 3-pin ARM Serial Wire Debug (SWD) port
- 10 / 100 Ethernet PHY embedded
- Supports Auto Negotiation
- Full / Half Duplex
- 10 / 100 Based
- Built-in RJ45(RB1-125BAG1A)
- Built-in LDO (LM8805SF5-33V)
