Grove - GPS (Air530)
Are you confused about your GPS not working well in urban areas? Then you should not miss our new Air530 GPS! It’s a high-performance, multi-mode satellite positioning and navigation module to use with Arduino. It supports GPS / Beidou / Glonass / Galileo / QZSS and SBAS, which makes it suitable for GNSS positioning applications, such as car navigation, smart wear, and drones. This module is capable of receiving more than 6 satellites at the same time, and is able to work with a bad signal.
Features
- High precision Positioning: Positioning error within 10 meters, and will still be accurate with a bad signal
- The Integrated Design of RF Baseband: Adopt the integrated design of RF baseband, which integrates DC/DC, LDO, LNA, RF front-end, baseband processing, 32-bit RISC based chip, RAM, FLASH storage, RTC, and power management functions
- Low Power Consumption: Low power consumption at only 31uA
- High Compatibility: Compatible hard/soft interface for other modules
- Product number: Seeed 109020022
Specifications
| Parameters | Values | |
| Supply voltage | 3.3V/5V | |
| Working current | up to 60mA | |
| Interface | UART | |
| Time of warm start | 4s | |
| Time of cold boot | 30s | |
| Working Temperature | -35C-85°C | |
| Storage Temperature | -55°C-100°C | |
| Humidity | 5%-95% | |
| Time of Positioning | Pure hardware cold start | 27.5s |
| Pure hardware hot start | <1S | |
| Pure hardware recapture | <1S | |
| Software-assisted A-GNSS | <5S | |
| Sensitivity | Cold start | -148dBm |
| Hot Start | -162dBm | |
| Recapture | -164dBm | |
| Track | -166dBm | |
| Accuracy | Horizontal positioning accuracy | 2.5m |
| High positioning accuracy | 3.5m | |
| Speed accuracy | 0.1m/s | |
| Time transfer accuracy | 30ns | |
| Consumption | Capture current [email protected] | 42.6mA |
| Tracking current [email protected] | 36.7mA | |
| Low power [email protected] | 0.85mA | |
| Ultra-low-power [email protected] | 31uA |
Resources
Pinout
Package Contents
- 1x GPS (Air 530) board
- 1x Grove cable
